| Product number |
3AL28AA |
| Display type |
IPS with LED backlight |
| DISPLAY SPECIFICATIONS |
| Display size (diagonal) |
23.8″ |
| Display area (metric) |
52.7 x 29.64 cm |
| Aspect ratio |
16:9 |
| Resolution (maximum) |
FHD (1920 x 1080 @ 60 Hz) |
| Resolution (native) |
FHD (1920 x 1080 @ 60 Hz) |
| Resolutions supported |
1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 800; 1366 x 768; 1440 x 900; 1600 x 900; 1680 x 1050; 1920 x 1080; 640 x 480; 720 x 400; 800 x 600 |
| Pixel pitch |
0.274 mm |
| Brightness |
300 cd/m² |
| Contrast ratio |
1000:1 static; 10000000:1 dynamic |
| Response time |
5 ms gray to gray (with overdrive) |
| Display scan frequency (horizontal) |
Up to 86 kHz |
| Display scan frequency (vertical) |
Up to 75 Hz |
| Onscreen controls |
Brightness; Color control; Contrast; Exit; Image control; Information; Input source; Language; Management; Menu; OK; Power |
| Display features |
Anti-glare; Anti-static; In plane switching; Language selection; LED backlights; On-screen controls; Plug and Play; User programmable |
| Tilt |
Tilt: -5 to +25° |
| CONNECTIVITY |
| Display Input Type |
1 VGA; 1 HDMI 2.0 |
| Display input type note |
(with HDCP support) |
| DIMENSIONS AND WEIGHT |
| Dimensions without stand (W x D x H) |
53.98 x 4 x 32.3 cm |
| Dimensions with stand (W x D x H) |
53.98 x 18 x 40.88 cm |
| Weight |
2.84 kg |
| POWER AND OPERATING REQUIREMENTS |
| Power |
Input voltage 100 to 240 VAC |
| Power Consumption Description |
22 W (maximum), 20 W (typical), 0.3 W (standby) |
| Operating temperature range |
5 to 35°C |
| ENERGY EFFICIENCY AND CERTIFICATIONS |
| Energy Efficiency Compliance |
ENERGY STAR® certified; EPEAT® Silver registered |
| Environmental |
Arsenic-free display glass; Mercury-free display backlights; Low halogen |
| Environmental specification footnote number |
[2] External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be Low Halogen. |
| Certifications and compliances |
BSMI; CB; CCC; CE; CEL Grade 2; CSA; CSA-NRTL; EAC; E-standby; EUP Lot-6; FCC; GEMS; HRN N N0.201; ICES; IEC 60950-1; IS 1121; ISO 9241-307; KC; KCC; MEPS; Microsoft WHQL Certification (Windows 10, Windows 8 and Windows 7); PSB; RCM; SABS IEC 60950-1; SASO; SmartWay Transport Partnership (NA); TUV Bauart; VCCI; ISC; Low blue light |
| WARRANTY AND SECURITY |
| Warranty |
3 Years On-Site warranty |
| Physical security |
Security lock-ready |
