Description
MODEL
MPY-7501-SFHAGV
ATX VERSION
SFX 12V Ver. 3.42
PFC
Active PFC
INPUT VOLTAGE
90-264V
INPUT CURRENT
10-5A
INPUT FREQUENCY
47-63Hz
DIMENSIONS (L X W X H)
100 x 125 x 63.5 mm
FAN SIZE
92mm
FAN BEARING
FDB
EFFICIENCY
90% @ Typical Load
80 PLUS RATING
80 PLUS Gold
ERP 2014 LOT 3
Yes
OPERATING TEMPERATURE
0-50°C
POWER GOOD SIGNAL
100 – 500 ms
HOLD UP TIME
16ms
MTBF
>100,000 Hours
PROTECTIONS
OVP, OPP, SCP, OCP, UVP, OTP, Surge and Inrush Protection
REGULATORY
TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, KCC, CB
ATX 24-PIN CONNECTORS
1
EPS 4+4 PIN CONNECTORS
1
EPS 8 PIN CONNECTOR
1
SATA CONNECTORS
8
PERIPHERAL 4-PIN CONNECTORS
4
PCI-E 6+2 PIN CONNECTORS
4
SERIE
V Gold Series, V SFX Gold Series
80 PLUS
Gold
MODULAR
Full Modular
WATTAGE
500 to 750W
