Transcend MTE110 128GB M.2 NVME PCIE SSD

Appearance

Dimensions80 mm x 22 mm x 3.58 mm (3.15″ x 0.87″ x 0.14″)Weight8 g (0.28 oz)

Interface

Bus Interface

• NVMe PCIe Gen3 x4

Storage

Flash Type

• 3D NAND flash

Capacity

• 128 GB/
• 256 GB/
• 512 GB/
• 1 TB

Operating Environment

Operating Temperature0°C (32°F) ~ 70°C (158°F)Operating Voltage

• 3.3V±5%

Performance

Sequential Read/Write (ATTO)

• 1 TB1,700/1,500 MB/s
• 512 GB1,700/1,500 MB/s
• 256 GB1,600/800 MB/s
• 128 GB1,500/400 MB/s

Sequential Read/Write (CrystalDiskMark)

• 1 TB1,700/1,500 MB/s
• 512 GB1,700/1,500 MB/s
• 256 GB1,600/800 MB/s
• 128 GB1,500/400 MB/s

4K Random Read/Write (IOmeter)

• 1 TB160,000/140,000 IOPS
• 512 GB160,000/140,000 IOPS
• 256 GB110,000/95,000 IOPS
• 128 GB90,000/90,000 IOPS

Terabytes Written (TBW)

• 1 TB400 TBW
• 512 GB200 TBW
• 256 GB100 TBW
• 128 GB50 TBW

Mean Time Between Failures (MTBF)1,000,000 hour(s)Drive Writes Per Day (DWPD)0.2 (5 yrs)Note

• Speed may vary due to host hardware, software, usage, and storage capacity.
• The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
• Some motherboards only provide PCIe x2 connections for the M.2 slot, creating a bottleneck on even the fastest drives.

Warranty

Certificate

• CE/
• FCC/
• BSMI

Warranty

• Five-year Limited Warranty

Warranty Policy

• Please click here for more information about the Transcend Warranty Policy.
• Warranty does not apply when SSD Scope’s wear-out indicator displays 0% within the warranty coverage.

System Requirement

Operating System

• Microsoft Windows 7 (additional driver required)
• Microsoft Windows 8 (additional driver required)
• Microsoft Windows 10
• Linux Kernel 2.6.31 or later
